T-9000 Gear Oils have been designed for oil and reservoir applications where abnormal temperatures are encountered. Recommended for the lubrication of gears, circulating systems, plain and anti-friction bearings, journals and metal-to-metal sliding loads.
T-9000 Oils are formulated from selected polyglycol fluids to assure naturally high viscosity index (VI) ratings for extended temperature stability in areas where a wide range of temperature highs and lows can be experienced. The natural high protection is supplemented with selective additives to provide maximum lubricating film strength, anti-wear protection and a longer, effective service life.
T-9000 Oils are multi-grade rated which eliminates summer/winter change over. They are particularly suited to worm gear applications where both high rolling and sliding loads are present.
T-9000 reduces friction, increases gearbox efficiency and is resistant to aging.
T-9000 Oils are not miscible with mineral oils. They are compatible with most seals with NBR, FKM or VMO types recommended. They are NOT compatible with neoprene (polychloroprene) or butadeini-mixed polymers and may attack some machine paints. Suitability testing should be conducted in application areas of uncertainty.
Typical Properties
Product | T-9068 | T-9100 | T-9150 | T-9220 | T-9320 | T-9460 | T-9680 |
---|---|---|---|---|---|---|---|
ISO VG | 68 | 100 | 150 | 220 | 320 | 460 | 680 |
AGMA | 2EP | 3EP | 4EP | 5EP | 6EP | 7EP | 8EP |
Viscosity | |||||||
cSt @ 40 0C | 68 | 100 | 150 | 240 | 320 | 468 | 680 |
cSt @ 100 0C | 13.5 | 18.8 | 27 | 41 | 52.4 | 75.3 | 111 |
SUS @ 100 0F | 315 | 463 | 695 | 1112 | 1482 | 2168 | 3150 |
SUS @ 210 0F | 71 | 93 | 129 | 193 | 245 | 352 | 518 |
Viscosity Index | 201 | 209 | 218 | 226 | 230 | 243 | 263 |
Flash Point | |||||||
COC 0F/0C | 446/230 | 448/230 | 483/250 | 540/282 | 540/282 | 540/282 | 540/282 |
Pour Point | |||||||
0F/0C | -40/-40 | -40/-40 | -35/-37 | -25/-32 | -25/-32 | -20/-30 | -15/-26 |
FZC Text- Load | |||||||
Stages passed (DIN 51354) | 12+ | 12+ | 12+ | 12+ | 12+ | 12+ | 12+ |
Timeken Load Test | |||||||
OK Load,kg/Ibs | 23/50 | 23/50 | 23/50 | 25/55 | 25/55 | 25/55 | 25/55 |
